 CPU |
Supports Intel® Core™ 2 Duo / Quad processors with 1600/1333/1066/800MHz FSB
Supports Intel® Core™ 2 Extreme/Quad/Duo & Pentium® Extreme Edition, Pentium® D, Pentium® 4 Processors, Pentium® Dual Core
Digital PWM Designation provide high quality and efficient power
|
| Chipset |
Intel® X38 Express / ICH9R Chipset
|
| Memory |
4 X 240-pin DIMM sockets support max. memory capacity 8GB
Supports Dual channel DDR2 1066/800/667 Un-buffered Non-ECC memory
|
| LAN |
On board PCI Gigabit LAN controller supports 10/100/1000M Ethernet
|
| Audio |
On board 7.1 CH HD Audio CODEC
Supports auto jack sensing and optical S/PDIF In/Out
HDMI audio ready header (S/P DIF header)
|
| Expansion Slots |
2 x PCI-E X16 (support PCI Express 2.0), 1 x PCI-E X16 (x4 bandwidth), 1 x PCI-E X1, 2 x PCI
|
| Internal I/O |
1 x Floppy Port supports up to 2.88 MB
1 x ATA 133/100/66 IDE connector
6 x SATA 3Gb/s connectors
1 x IEEE1394, 4 x USB header (support 8 ports)
1 x FP-Audio
|
| Back Panel I/O |
1 x PS/2 Keyboard, 1 x PS/2 Mouse
abit Silent OTES™
1 x S/P DIF In, 1 x S/P DIF Out
2 x eSATA
7.1 CH Audio connector (Front, Line-in, MIC-in, Center/Subwoofer, Surround, Rear Surround)
1 x 1394, 4 x USB 2.0, 1 x RJ-45 LAN connector,
Clear CMOS Button
|
| Serial ATA |
6 x SATA 3Gb/s offer by Intel® ICH9R support Intel® Matrix Storage Tech(AHCI & RAID0/1/5/10)
2 x eSATA 3Gb/s through JMicron® JMB363 support 0,1JBOD RAID
|
| IEEE 1394 |
Supports 2 Ports IEEE 1394 at 400Mb/s transfer rate.
|
| Form Factor |
ATX form factor 305 x 245mm
PCB Color: Blue
|
| RoHS |
100% lead-free process and RoHS compliant
|
| abit Engineered |
abit µGuru™ Technology
abit Silent OTES™ Technology
100% Low ESR and high ripple conductive polymer aluminum solid state capacitors
New Generation digital PWM
EZ for CCMOS
On board LED Lighting
Quick Power On/Off & Reset buttons
right angle SATA connectors
|
abit Engineered |
 |
 abit µGuru
With abit's unique µGuru technology now even the most novice users can fully monitor and control their system including voltages, fans and temperatures; it's all just a click away. The more advanced you become, the more you will appreciate the multitude of fine tuning features abit's µGuru technology holds for you.
|
 |
OC Guru - AutoDrive™
By enabling AutoDrive, you can automatically apply different overclocking settings for different applications.
|
 |
Hardware Monitoring
Monitor temperatures, voltages and fan settings in real time and with zero CPU usage.
 Dedicated fan control
Keep control over your hardware. abit Fan EQ™ helps you keep an eye on your motherboard fans.
|
 |
One Click BIOS Update
With abit's BIOS flash utility you can easily update your motherboard BIOS online or offline.
|
 |
Auto-Detect Hardware Info
The abit BlackBox auto-detects hardware info for quick communication between users and abit Tech support.
|
 |
abit SoftMenu™
The original jumperless motherboard design allows for CPU setting changes completely through the BIOS. For GigaOverclocking! Boost your PC's Performance by up to 50%. Convenient and easy-to-use fine tuning from within a self-explanatory BIOS menu.
|
 |
abit CPU ThermalGuard™
The abit CPU ThermalGuard™ technology prevents the CPU from overheating and burning up in the case of any hardware cooling malfunction. This hardware thermal protection automatically shuts down your system when the CPU temperature reaches a certain threshold.
|
